The All-In-One Controller for Your Outdoor Lights
Need assistance on deciding which controller is right for your installation? We are here to help, click on the Advice Link or drop us a note on Whatsapp for instant assistance (During Business Hours).
Model Comparison
- Model NumberModel Number
APP Control APP Control- Supply VoltageMains 220v AC is supplied to the controller for internal power, 24v DC power is supplied from a transformer as a supply to the lights the box is connected to. Supply Voltage
- DC Output TransformerDC Output Transformer
- DC OutputDC Output
- 2 Wire Pool Light Control2 Wire Pool Light Control
- 2 Wire Inground Light Control 2 Wire Inground Light Control
- Traditional (220v AC) Control (on/off)Traditional (220v AC) Control (on/off)
- 2 Wire Group Channels2 Wire Group Channels
- Wireless Group ChannelsWireless Group Channels
- 220v Relay(s)220v Relay(s)
- WiFI RequiredWiFI Required
- Remote Control outside of homeRemote Control outside of home
1.1.0
- Model NumberSmartLINK 1.1.0
- APP Control
- Supply Voltage220v AC
- DC Output TransformerInternal (Included)
- DC Output200w
- 2 Wire Pool Light Control
- 2 Wire Inground Light Control
- Traditional (220v AC) Control (on/off)None
- 2 Wire Group ChannelsIncludes 1 (2 Wire) Channel - All lights connected to this channel will be controlled as a single group together1
- Wireless Group ChannelsIncludes 1 group for wireless control1
- 220v Relay(s)N/A
- WiFI RequiredA WiFi connection is not required for controls to work within range of the control box (aprox 10-30m)No
- Remote Control outside of homeA WiFi connection is required in order to control the lights and see status of lights outside of the homeWiFi Required
2.8.1
- Model NumberSmartLINK 2.8.1
- APP Control
- Supply Voltage220v AC
- DC Output TransformerInternal (Included)
- DC Output200w / 350w / 500w
- 2 Wire Pool Light Control
- 2 Wire Inground Light Control
- Traditional (220v AC) Control (on/off)
- 2 Wire Group ChannelsIncludes 2 separate (2 Wire) Channels - This enables two separate groups of lights to be controlled independently. 2
- Wireless Group ChannelsIncludes up to 8 groups for wireless control8
- 220v Relay(s)Includes 1 220v AC relay - can be connected directly or to an outlet to control traditional lights, water features, etc.1
- WiFI RequiredA WiFi connection is not required for controls to work within range of the control box (aprox 10-30m)No
- Remote Control outside of homeA WiFi connection is required in order to control the lights and see status of lights outside of the homeWiFi Required
PRO
- Model NumberSmartLINK PRO
- APP Control
- Supply Voltage220v AC
- DC Output TransformerInternal (Included)
- DC Output200w / 350w / 500w
- 2 Wire Pool Light Control
- 2 Wire Inground Light Control
- Traditional (220v AC) Control (on/off)
- 2 Wire Group ChannelsTBC
- Wireless Group ChannelsTBC
- 220v Relay(s)TBC
- WiFI RequiredA WiFi connection is not required for controls to work within range of the control box (aprox 10-30m)No
- Remote Control outside of homeA WiFi connection is required in order to control the lights and see status of lights outside of the homeWiFi Required
Connect Everything
